Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.8 Line connection variations
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-35
2.8.3 Operation of the line connection components via an autotransformer
An autotransformer can be used for voltage adaptation in the range up to 3AC 480 V +10%.
Caution
To ensure safe electrical separation, an isolating transformer must be installed with voltages
greater than 3AC 480 V +10%.
Applications:
• The motor insulation must be protected from excessive voltages.
• The active line module must provide a stabilized DC link voltage. It can be in the range
380 V to 415 V.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
