6.5 DRIVE-CLiQ Coupling
Equipment Manuel for Booksize Power Modules
6-38 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
6.5.3 Interface Description
6.5.3.1 Overview




Figure 6-20 DRIVE-CLiQ Coupling
1
DRIVE-CLiQ Coupling
2
Type plate
3
Centering caps
6.5.4 Dimension drawing
%
E


+
7
Figure 6-21 Dimension drawing of the DRIVE-CLiQ Coupling
Accessories B [mm] H [mm] T [mm]
DRIVE-CLiQ Coupling 81.5 (3.20) 33 (1.29) 30.7 (1.20)
