Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.4 Wideband Line Filter for Active Line Modules
Equipment Manuel for Booksize Power Modules
2-12 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2.4.3.1 Line/load connection
A Wideband Line Filter for Active Line Modules is rated for a voltage range of 380 V
3AC -10% to 480 V 3AC +10% (-15% <1 min) at 47 Hz to 63 Hz.
Table 2-5 Type of connection
Terminals Designations
Line connection (line) L1, L2, L3, PE
Load connection (load) U, V, W
Wideband Line Filter for Active Line Modules
16 kW Screw terminal: 10 mm
2
3-pin/1.5 Nm (see Screw Terminals)
Ground stud: M5/3 Nm
1)
36 and 55 kW Screw terminal: 50 mm
2
3-pin/6 Nm (see Screw Terminals)
Ground stud: M8/13 Nm
1)
80 kW Screw terminal: 95 mm
2
3-pin/15 Nm (see Screw Terminals)
Ground stud: M8/13 Nm
1)
120 kW Connection strap: d = 11 mm (M10/25 Nm)
Ground stud: M8/13 Nm
1)
Note: No shock-hazard protection (IP00)
1) for ring cable lugs to DIN 46234
