Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.6 Line reactors for Active Line Modules
Equipment Manuel for Booksize Power Modules
2-22 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2.6.3.1 Line/load connection
Table 2-12 Connection methods for line reactor
Terminals Designations
Line connection 1U1, 1V1, 1W1, PE
Load connection 1U2, 1V2, 1W2
Line reactors for Active Line Modules
16 kW Screw terminal 16 mm
2
3–pin / 6 Nm*
36 kW Screw terminal 35 mm
2
3–pin / 6 Nm*
55 kW Screw terminal 70 mm
2
3–pin / 6 Nm*
80 kW Connection strap d = 9 mm
2
(M10/25 Nm) for ring cable lugs to DIN 46234
Note: No shock-hazard protection (IP00)
120 kW Connection strap d = 10 mm
2
(M10/25 Nm) for ring cable lugs to DIN 46234
Note: No shock-hazard protection (IP00)
*
See Screw Terminals
