Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.5 Line filters for Smart Line Modules
Equipment Manuel for Booksize Power Modules
2-14 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2.4.5 Technical Specifications
Table 2-7 Technical specifications: Wideband Line Filter for Active Line Modules
6SL3000
unit
0BE21-
6AA0
0BE23-
6AA0
0BE25-
5AA0
0BE28-
0AA0
0BE31-
2AA0
Rated power kW 16 36 55 80 120
Connection voltages:
Supply voltage
Line frequency
V
AC
Hz
3AC 380 -10% to 3AC 480 +10% (-15% < 1 min)
47 to 63 Hz
Rated current A
AC
30 67 103 150 225
Power loss
1
W 70 90 110 150 200
Weight kg 9 16 19 22 32
1
For an overview, see the power loss tables in Cabinet Design.
2.5 2.5 Line filters for Smart Line Modules
2.5.1 Description
The line filters for Smart Line Modules are designed for use in machines in which the
conducted interference in the frequency range is to be reduced in accordance with EMC
regulations. The machine manufacturer must carry out EMC-compliant CE certification for
the product before it is implemented.
General conditions regarding line filters for Smart Line Modules
• In conjunction with the line filters and the associated line reactors, drive line-ups with
Basic Line Modules fulfill the requirements of limit value class A1 to EN55011.
• The total cable length is ≤ 350 m.
