7.5 Information about electromagnetic compatibility (EMC) and cable laying
Equipment Manuel for Booksize Power Modules
7-20 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7.5 7.5 Information about electromagnetic compatibility (EMC) and
cable laying
7.5.1 General
EMC requirements can be found in EN 60439-1 and recommendations in EN60204-1. The
EMC installation guide can be obtained using the order number 6FC5297-☐AD30-0AP☐.
For installing components in cabinets, the following conditions must be ensured to comply
with the EMC Directive:
• Operation in TN systems with SINAMICS line filters
• Observance of information about cable shielding and equipotential bonding
• Only the recommended Siemens power and signal cables are used
• Only cables from Siemens must be used for DRIVE-CLiQ connections.
For MOTION-CONNECT cables see catalog D21.1 or D21.2
Caution
No cables or couplings that you have prefabricated yourself must be used for DRIVE-CLiQ
connections.
