Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.7 Line reactors for Smart Line Modules
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-25
2.7 2.7 Line reactors for Smart Line Modules
2.7.1 Description
The line reactors for Smart Line Modules limit low-frequency line reactions to permissible
values.
2.7.2 Safety information
Caution
A ventilation clearance of 100 mm must be maintained around the component (not including
the mounting surface).
Note
The connection cables to the Line Module must be as short as possible (max. 10 m).
If possible, they should be shielded.
Unless it can otherwise be avoided, cables must be routed past the line reactor at a
minimum distance of 150 mm.
Caution
Only the line reactors described in this Equipment Manual must be used.
Using line reactors not approved by SIEMENS for SINAMICS 6SL31:
- The Line Modules may become damaged/faulty.
- cause line reactions that can damage or destroy other loads powered from the same
network.
Caution
The surface temperature of the line reactors may exceed 80 °C.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
