Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.7 Line reactors for Smart Line Modules
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-27
2.7.3.1 Line/load connection
Table 2-16 Connection methods for line reactor
Terminals Designations
Line connection 1U1, 1V1, 1W1, PE
Load connection 1U2, 1V2, 1W2
Line reactors for Smart Line Modules
5 kW Screw terminal 4 mm
2
3-pin*
10 kW Screw terminal 10 mm
2
3-pin*
16 kW Screw terminal 10 mm
2
3-pin* with PE connection for ring cable lug M5 to DIN 46234
36 kW Screw terminal 16 mm
2
3-pin* with PE connection for ring cable lug M6 to DIN 46234
*
See Screw Terminals

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
