2.5 Line filters for Smart Line Modules
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-17
2.5.3.2 Line/load connection
Line filters for Smart Line Modules are rated for a voltage range from 380 V 3AC -10% to
480 V 3AC +10% (-15% <1 min) at 47 Hz to 63 Hz.
Table 2-8 Type of connection
Terminals Designations
Line connection (line) L1, L2, L3, PE
Load connection (load) L1´, L2´, L3´, PE
Line filters for Smart Line Modules
5 kW Screw terminal: 10 mm
2
3-pin/1.5 Nm (see Screw Terminals)
Ground stud: M6/4.8 Nm
1)
10 kW Screw terminal: 10 mm
2
3-pin/1.5 Nm (see Screw Terminals)
Ground stud: M6/4.8 Nm
1)
16 kW Screw terminal: 10 mm
2
3-pin/1.5 Nm (see Screw Terminals)
Ground stud: M6/3 Nm
1)
36 kW Screw terminal: 35 mm
2
Ground stud: : M6/3 Nm
1)
1) for ring cable lugs to DIN 46234
