Options
6.3 DC link adapter
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
6-29
6.3.3.2 DC link connection
Table 6-12 DC link adapter – description of the terminals
Terminal Function Technical specifications
DCP DC link positive
DCN DC link negative
Two-row configuration of adapter 35 – 95 mm²
Current carrying capacity: 240 A
Voltage: 750 V-VDE/600 V AC
Connection cross-section: 35 – 95 mm²
Stripped length: 27 mm
