Siemens SINAMICS Series Equipment Manual

Options
6.5 DRIVE-CLiQ Coupling
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
6-37
6.4.6 Technical specifications
Table 6-16 Technical Specifications
DRIVE-CLiQ Flanged Coupling
6FX2003-0DC0x
Unit
Weight kg 0.135
Degree of protection IP20 to EN 60 529 inside the cabinet
IP54 to EN 60 529 outside the cabinet
6.5 6.5 DRIVE-CLiQ Coupling
6.5.1 Description
The DRIVE-CLiQ Coupling is used to connect two DRIVE-CLiQ cables in accordance with
degree of protection IP67.
In addition to the data lines, the power supply contacts of DRIVE-CLiQ are also routed via
the coupling.
6.5.2 Safety information
Caution
Only cables from Siemens must be used for DRIVE-CLiQ connections.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
