Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.8 Line connection variations
Equipment Manuel for Booksize Power Modules
2-34 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2.8.2 Operation of the line connection components on the supply network
The SINAMICS S booksize drive system is rated for direct operation on TN, TT, and IT
supply systems with a nominal voltage of 3AC 380 V to 3AC 480 V. Operation with a line
filter is only permitted for a TN supply system.
OLQHBGLUFRQYVG
/
2WKHU
FRQVXPHUV
/
3(
/
:98
'&3 '&1
)XVHV
/LQHFRQWDFWRU
/LQHILOWHU
RSWLRQDO
/LQHUHDFWRU
/LQHPRGXOH
Figure 2-17 Direct operation on the supply network

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
