Siemens SINAMICS Series Equipment Manual

Options
6.2 DC link supply adapter
Equipment Manuel for Booksize Power Modules
6-20 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
6.2.3.2 DC link connection
Table 6-7 DC link supply adapter – description of the terminals
Terminal Function Technical specifications
DCP DC link positive
DCN DC link negative
Connection voltage:
750 V-VDE/600 V-UL
Direct supply 4 – 10 mm²
Current carrying capacity: 36 A
Connection cross-section: 4 – 10 mm²
Stripped length: 11 mm
Direct supply 35 – 95 mm²
Current carrying capacity: 240 A
Connection cross-section: 35 – 95 mm²
Stripped length: 27 mm
