Siemens SINAMICS Series Equipment Manual

DC link components Booksize
5.3 Capacitor Module
Equipment Manuel for Booksize Power Modules
5-16 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
5.3.6 Technical Specifications
Table 5-7 Technical Specifications
Capacitor Module
Electronics power supply V
DC
24 (20.4 - 28.8)
DC link voltage V
DC
510 - 750
Capacitance μF 4000
24 V DC busbar
current carrying capacity
A 20
DC link busbar current carrying
capacity
A 100
Power loss
1
W 25
Weight kg 7.2
1
For an overview, see the power loss tables in Cabinet Design.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
