System overview
1.7 System Data
Equipment Manuel for Booksize Power Modules
1-10 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
1.7 1.7 System Data
Technical Specifications
Unless explicitly specified otherwise, the following technical specifications are valid for
components of the SINAMICS S120 booksize drive system.
Electrical specifications
Line connection voltage 3 AC 380 V to 480 V ±10 %
(-15 % < 1 min)
Line frequency 47 – 63 Hz
Electronics power supply 24 V DC, -15/+20 %*
Conducted radio interference
• Standard
• With line filter
No conducted radio interference
Class A1 to EN 55011
Overvoltage category Class III to EN 60 664-1
*
If a motor holding brake is used, restricted voltage tolerances may have to be taken into account.
Modules
Line Modules in booksize format
• Rated supply voltage
3AC 380 V
Active Line Modules in booksize format
• Rated pulse frequency
8 kHz
Motor Modules in booksize format
• DC link connection voltage
• Rated pulse frequency
510 V DC to 750 V DC
4 kHz
Ambient conditions
The Safety-Integrated safety function:
The components must be protected against conducted contamination (e.g. by installing them in a cabinet with degree of
protection IP54).
Provided that conducted interference can be prevented at the installation site, the degree of protection for the cabinet can
be decreased accordingly.
Degree of protection IP20 to EN 60 529
Protection class Class I (with protective conductor system) and
Class III (PELV) to EN 61 800-5-1
Permissible ambient and coolant temperature (air) during
operation for line-side components, Line Modules and Motor
Modules
0°C to 40 °C without derating,
>40°C to +55 °C (see derating characteristics)
Permissible ambient and coolant temperature (air) during
operation for DC link components
0 °C to +55 °C
