System overview
1.7 System Data
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
1-11
Information on storage, transportation and operation:
Environmental class
• Storage
• Transportation
• Operation
Class 1C2 to EN 60 721-3-1
Class 2C2 to EN 60 721-3-2
Class 3C2 to EN 60 721-3-3
Organic/biological influences
• Storage
• Transportation
• Operation
Class 1B1 to EN 60 721-3-1
Class 2B1 to EN 60 721-3-2
Class 3B1 to EN 60 721-3-3
Vibratory load
• Transportation
• Operation
EN 60 721-3-2, class 2M3
EN 60 721-3-3, class 3M4
Shock load
• Transportation
• Operation
EN 60 721-3-2, class 2M3
EN 60 721-3-3, class 3M3
Climatic ambient conditions
• Storage
• Transportation
• Operation
Class 1K3 to EN 60 721-3-1
Temperature: -40 °C to +70 °C
Class 2K4 to EN 60 721-3-2
Temperature: -40 °C to +70 °C
Max. humidity: 95 % at 40 °C
Class 3K3 to EN 60 721-3-3
Relative air humidity 5 to 65 % (annual average,
≦ 80 % above the maximum for 2 months a year.
Avoid splashing water and do not allow condensation or ice
to form (EN 60 204, Part 1)
Degree of contamination 2 to EN 60 664-1
Installation altitude Up to 1,000 m above sea level without derating,
>1,000 m to 5,000 m above sea level (see derating
characteristics)
Approbation
Certification CE (low-voltage and EMC Directives), cULus
(file pos.: E192450, E164110, E70122, and E214113)
