Options
6.2 DC link supply adapter
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
6-19
6.2.3 Interface description
6.2.3.1 Overview
'&OLQNVXSSO\DGDSWHU
Figure 6-11 150 mm modules with DC link supply adapter for 35 mm² to 95 mm² and 100 mm
modules with DC link supply adapter for 4 mm² to 10 mm²
