Siemens SINAMICS Series Equipment Manual

Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
B-1
B References
B
SINAMICS Documentation
Catalogs
/D11.1/ SINAMICS G110 Inverter Chassis Units 0.12 kW to 3 kW
Order no.: E86060-K5511-A111-A2, edition: 10.2005
/D11/ SINAMICS G130 Drive Converter Chassis Units, SINAMICS G150 Drive Converter
Cabinet Units
Order no.: E86060-K5511-A101-A2, edition: 07.2004
/D21.1/ SINAMICS S120 Vector Control Drive System
Order no.: E86060-K5521-A111-A1, edition: 04.2005
/D21.2/ SINAMICS S120 Servo Control Drive System
Order no.: E86060-K5521-A121-A1, edition: 04.2004
/D21.3/ SINAMICS S150 Drive Converter Cabinet Units
75 kW to 1200 kW
Order no.: E86060-K5521-A131-A1, edition: 05.2004
Related catalogs
/ST70/ SIMATIC Components for Totally Integrated Automation, catalog ST70
Ordering information
Order no.: E86060-K4670-A111-A9, edition: 10.2004
/PM10/ Motion Control System SIMOTION, catalog PM10
Ordering information
Order no.: E86060-K4910-A101-A5, edition: 07.2005
Interactive catalogs
/CA01/ The Offline Mall of Automation and Drives
CD-ROM
Order no.: E86060-D4001-A100-C3, edition: 10.2004
/Mall/ A&D Mall, Catalog and Online Ordering System
http://www.siemens.com/automation/mall

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
