Siemens SINAMICS Series Equipment Manual

Line Connection Booksize
2.6 Line reactors for Active Line Modules
Equipment Manuel for Booksize Power Modules
2-24 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Figure 2-11 Dimension drawing: line reactor for Active Line Modules as of 80 kW
Table 2-14 Dimensions of the line reactor for Active Line Modules
Order
number
L [mm]
(inches)
W [mm]
(inches)
h1 [mm]
(inches)
h2 [mm]
(inches)
H [mm]
(inches)
b [mm]
(inches)
n
1
[mm]
1)
(inches)
n
2
[mm]
1)
(inches)
n
3
[mm]
1)
(inches)
80 kW 6SN1111-
0AA00-
1EA0
380
(14.96)
225
(8.86)
50 (1.70) 170
(6.69)
220
(8.66)
170
(6.69)
175
(6.89)
325
(12.80)
156 (6.14)
120 kW 6SL3000-
0DE31-
2BA0
490
(19.29)
225
(8.86)
60 (2.36) 220
(8.66)
250
(9.84)
170
(6.69)
175
(6.89)
325
(12.80)
156 (6.14)
1) The lengths n1, n2 and n3 correspond to the drill hole spacing
2.6.5 Technical specifications
Table 2-15 Technical specifications of line reactors for the Active Line Module
6SN1111–
Unit
0BA1 0CA1 0DA1 1EA0 1FA0
Output kW 16 36 55 80 120
Rated current A
rms
30 67 103 150 225
Power loss
1
W 170 250 350 450 590
Weight [kg] 8.5 13 18 40 50
1
For an overview, see the power loss tables in Cabinet Design.
