Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.1 Information
Equipment Manuel for Booksize Power Modules
7-2 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7.1.2 Safety information
Note
When installing the equipment in cabinets, the ventilation slots must be covered to prevent
drill swarf, wire end ferrules, and the like from falling into the housing.
Safety regulations governing shock protection must be observed. See also EN 60204–1.
Caution
The tightening torque of the DC link busbar screws (1.8 Nm) must be checked before
startup.
To ensure that the encoder system works properly, you are advised to use the original
Siemens accessories from catalogs D21.1 and D21.2.
Only motors with a safe electrically isolated holding brake may be connected. The brake
conductors must also be safely electrically isolated.
If the motor power cable is connected to intermediate terminals, the power cables and brake
cables must be routed apart (≥ 300 mm).
After an intermediate terminal (e.g. due to a terminal block), it is best to continue routing
using the approved MOTION-CONNECT cable.
Warning
Cable shields and unused conductors of power cables (e.g. brake conductors) must be
connected to PE potential.
Non-observance can cause lethal shock voltages.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
