Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-1
Line Connection Booksize
2
2.1 2.1 Introduction
The line connection for a SINAMICS booksize drive line-up comprises an optional line filter
and a line reactor:
• Line filter variants:
– Basic Line Filter for Active Line Modules
– Wideband Line Filter for Active Line Modules
– Line filters for Smart Line Modules
• Line reactor variants:
– Line reactors for Active Line Modules
– Line reactors for Smart Line Modules
OLQHBFRQQHFWLRQYVG
/LQHILOWHU
RSWLRQDO
/LQHUHDFWRU
$&VXSSO\
IRU
OLQH
PRGXOH
Figure 2-1 Overview diagram: line connection
