Line Connection Booksize
2.2 Overview: line filters
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-3
2.2 2.2 Overview: line filters
In conjunction with a line reactor and an EMC-compliant plant configuration, line filters limit
the electromagnetic emissions from the Power Modules to the limit values of class A1 to
EN 55011.
Optional line filter rows that are coordinated with the power range are also available with the
SINAMICS S120 converter system. These line filters differ with regard to the frequency
range in which they reduce the conducted emissions.
Basic Line Filter for Active Line Modules
Basic Line Filters function in the frequency range from 150 kHz to 30 MHz. Above all, this
protects the radio services.
Wideband Line Filter for Active Line Modules
Wideband Line Filters also function in the frequency range from 2 kHz to 150 kHz. They help
reduce low-frequency line reactions. which protects consumers (e.g. electronic devices)
against functional impairments and damage when they are operated on the same network.
Line filters for Smart Line Modules
Line filters for Smart Line Modules function in the frequency range from 150 kHz to 30 MHz.
Above all, this protects the radio services.
Table 2-1 Overview
Order number
Basic Line Filter for Active Line Modules
16 kW 6SL3000-0BE21-6DAx
36 kW 6SL3000-0BE23-6DAx
55 kW 6SL3000-0BE25-5DA0
Wideband Line Filter for Active Line Modules
16 kW 3SL3000-0BE21-6AAx
36 kW 3SL3000-0BE23-6AAx
55 kW 3SL3000-0BE25-5AAx
80 kW 3SL3000-0BE28-0AAx
120 kW 3SL3000-0BE31-2AAx
Line filters for Smart Line Modules
5 kW 6SL3000-0HE15-0AAx
10 kW 6SL3000-0HE21-0AAx
16 kW 6SL3000-0BE21-6DAx
36 kW 6SL3000-0BE23-6DAx
