Options
6.4 DRIVE-CLiQ Flanged Coupling
Equipment Manuel for Booksize Power Modules
6-34 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
6.4.3 Interface Description
6.4.3.1 Overview






Figure 6-16 DRIVE-CLiQ Flanged Coupling
1
DRIVE-CLiQ Flanged Coupling
2
Centering cap
3
IP67 interface
4
Mounting holes
5
Type plate
6
IP20 interface
