2.3 Basic Line Filter for Active Line Modules
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
2-7
2.3.3.2 Line/load connection
The Basic Line Filter for Active Line Modules is rated for a voltage range of 380 V 3AC -10%
to 480 V 3AC +10% (-15% <1 min) at 47 Hz to 63 Hz.
Table 2-2 Type of connection
Terminals Designations
Line connection (line) L1, L2, L3, PE
Load connection (load) L1´, L2´, L3´, PE
Basic Line Filter for Active Line Modules
16 kW Screw terminal: 10 mm
2
3-pin/1.5 Nm (see Screw Terminals)
PE connection: M6/3 Nm
1)
36 kW Screw terminal: 35 mm
2
PE connection: M6/3 Nm
1)
55 kW Screw terminal: 50 mm
2
PE connection: M6/3 Nm
1)
1) for ring cable lugs to DIN 46234
