7.7 Cooling
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7-33
Table 7-14 Ventilation clearances above and below the components
Component Order number Clearance [mm]
CU320 6SL3040-0MA00-0AAx 80
SMCxx 6SL3055-0AA00-5xAx 50
TM31 6SL3055-0AA00-3AAx 50
Line filter for Line Module
5 kW - 120 kW 6SL3000-0BExx-xAAx 100
Line reactor for Active Line Module
16 kW – 120 kW 6SN1111-0AA00-xxAx 100
Line reactor for Smart Line Module
5 kW – 36 kW 6SL3000-0CExx-0AAx 100
Active Line Module
16 kW – 55 kW
80 kW – 120 kW
6SL3130-7TExx-xAAx
6SL3130-7TExx-xAAx
80
80 (additional 50 in front of fan)
Smart Line Module
5 kW – 36 kW 6SL3130-6AExx-0AAx 80
Motor Module < 132 A 6SL312x-1TExx-xAAx 80
Motor Module
132 A and 200 A 6SL312x-1TE3x-xAAx 80 (additional 50 in front of fan)
Braking Module 6SL3100-1AE31-0AAx 80
Control Supply Module 6SL3100-1DE22-0AAx 80
Capacitor Module 6SL3100-1CE14-0AAx 80
The specifications regarding ventilation clearances for two-tier configurations are provided in
Drive Line-Up.
Note
The distance between the blow-out aperture of the air conditioner and the electronic
equipment must be at least 200 mm.
