Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.7 Cooling
Equipment Manuel for Booksize Power Modules
7-34 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
PP
PP
0RXQWLQJVXUIDFH
&RRODLU
+RWDLU
Figure 7-14 Clearances for booksize drive line-up with internal air cooling

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
