Cabinet Configuration and EMC Booksize
7.3 24 V DC supply voltage
Equipment Manuel for Booksize Power Modules
7-10 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Component Typical current consumption [A
DC
]
Double Motor Modules
2 x 3 A (+2 x DRIVE–CLiQ; +2 x brake) 1.0
2 x 5 A (+2 x DRIVE–CLiQ; +2 x brake) 1.0
2 x 9 A (+2 x DRIVE–CLiQ; +2 x brake) 1.0
2 x 18 A (+2 x DRIVE–CLiQ; +2 x brake) 1.0
Braking Module 0.5
Sensor Modules
SMC10 0.25
SMC20 0.25
SMC30 0.33
Additional system components
TM31 (without digital outputs)
per digital output
0.12
0.1
The values specified refer to Motor Modules/Line Modules with internal/external cooling.
