Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.5 Information about electromagnetic compatibility (EMC) and cable laying
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
7-23
Table 7-11 Maximum cable lengths
Type Maximum length [m]
24 V DC power cables
2
10
24 V signal cables
2
30
DC link, including extensions 10
Total length of the power cables in the drive line-
up comprising: motor power cables, DC link
cable(s), and the power supply cable from the line
filter output
350 (shielded)
560 (unshielded)
Total length: motor cables, power supply cable
from the Basic Line Filter to the Active Line
Module
< 150
Total cable length with VCM 630 (shielded)
850 (unshielded)
Power cable between line filter and line reactor 10 (shielded/unshielded)
1
Power cable between line reactor and Line
Module
10 (shielded/unshielded)
1
Power cable between
Motor Module and motor 18 A
70 (shielded)
100 (unshielded)
Power cable between
Motor Module and motor ≤ 30 A
50 (shielded)
75 (unshielded)
Power cable between
Motor Module and motor ≥ 45 A
100 (shielded)
150 (unshielded)
DRIVE-CLiQ signal cables MC500 100
DRIVE-CLiQ signal cables MC800 50
DRIVE-CLiQ signal cables FIX 100
Cable between the Braking Module and braking
resistor
10
1
To comply with EMC limit values, shielded cables (preferably Motion Connect cables) must be used.
2
For greater lengths, suitable wiring must be connected by the user to provide overvoltage protection.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
