Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.6 Connection methods
Equipment Manuel for Booksize Power Modules
7-26 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Screw terminal type
Connectable conductor
cross-sections
Flexible
With wire end ferrule, without plastic sleeve
With wire end ferrule, with plastic sleeve
0.2 mm
2
to 4 mm
2
0.25 mm
2
to 4 mm
2
0.25 mm
2
to 4 mm
2
Insulation stripping length 7 mm
Tool Screwdriver 0.6 x 3.5 mm
4
Tightening torque 0.5 to 0.6 Nm
Connectable conductor
cross-sections
Flexible
With wire end ferrule, without plastic sleeve
With wire end ferrule, with plastic sleeve
0.5 mm
2
to 6 mm
2
0.5 mm
2
to 6 mm
2
0.5 mm
2
to 6 mm
2
Insulation stripping length 12 mm
Tool Screwdriver 1.0 x 4.0 mm
5
Tightening torque 1.2 to 1.5 Nm
Connectable conductor
cross-sections
Flexible
With wire end ferrule, without plastic sleeve
With wire end ferrule, with plastic sleeve
0.5 mm
2
to 10 mm
2
0.5 mm
2
to 10 mm
2
0.5 mm
2
to 10 mm
2
Insulation stripping length 11 mm
Tool Screwdriver 1.0 x 4.0 mm
6
Tightening torque 1.5 to 1.8 Nm

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
