Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.6 Connection methods
Equipment Manuel for Booksize Power Modules
7-28 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Figure 7-9 Removing the motor connector
The following figure shows how the motor connector is coded to prevent incorrect connection
(especially relevant for Double Motor Modules).
FRGBPRWRUVWYVG
&RGLQJSOXJV &RGLQJSOXJV
&RGLQJSOXJV
&RGLQJSOXJV
0RWRU
FRQQHFWRU
&RGLQJSOXJV
Figure 7-10 Coding the motor connector
The coding plugs are supplied with the motor cables.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
