Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.7 Cooling
Equipment Manuel for Booksize Power Modules
7-40 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
Unit Power loss
Wideband Line Filter for Smart Line Modules
5 kW W 5
10 kW W 9
16 kW W 16
36 kW W 28
Line reactors for Active Line Modules
16 kW W 170
36 kW W 250
55 kW W 350
80 kW W 450
120 kW W 590
Line reactors for Smart Line Modules
5 kW W 62
10 kW W 116
16 kW W 110
36 kW W 170
Sensor Modules
SMC20 W < 10
Additional system components
TM 15 W < 3
TM31 W < 10
CBE20 W 2.81
DC link components
Braking Module W 20
Capacitor Module W 25
Control Supply Module W < 105
Voltage Clamping Module W 50
The sum of the losses of the various power components (Active Line Module, Smart Line
Module, Motor Module) is calculated from the power losses (following table) and electronic
losses (next table but one).
