Siemens SINAMICS Series Equipment Manual

References
Equipment Manuel for Booksize Power Modules
B-4 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
/IKPI/ SIMATIC NET, Industrial Communication and Field Devices
Catalog
Order no.: E86060-K6710-A101-B4, edition: 2005
/PDP/ PROFIBUS Installation Guidelines
Installation Guideline for PROFIBUS-FMS/DP
Installation and Wiring Recommendation for RS 485 Transmission
Order no. 2.111 (German), Version 1.0
Order no. 2.112 (English), Version 1.0
Documentation for Safety Equipment
Note
For more information about technical documentation for Safety Integrated, visit the following
address:
http://www.siemens.com/safety
The following list contains some of the safety-related documentation available.
/LVP/ Low-Voltage Switchgear
Catalog
Order no.: E86060-K1002-P101-A5, edition: 2005
/LV10/ Controlgear for Industry
Catalog
Order no.: E86060-K1002-A101-A4, edition: 2004
/LV20/ BERO - Sensors for Automation
Catalog:
Order no.: E86060-K1803-A101-A3, edition: 2004
/LV30/ Products and Systems for Low-Voltage Power Distribution
Catalog
Order no.: E86060-K1801-A101-A4, edition: 2004
/MRL/ Directive 98/37/EG of the European Parliament and Council
Machinery Directive
Bundesanzeiger-Verlags GmbH, edition: 22.06.1998
/SIAH/ Safety Integrated
Application Manual
Order no.: 6ZB5000-0AA01-0BA1, 5th edition
/SICD/ Safety Integrated
CD-ROM
Order no.: E20001-D10-M103-X-7400, edition: 09.2004

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
