Line Modules Booksize
3.1 Introduction
Equipment Manuel for Booksize Power Modules
3-2 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
General characteristics of the Line Modules
Connection voltage: 3AC 380 V -10% to 3AC 480 V +10% (-15% <1 min) (47 to 63 Hz)
Suitable for TN, TT, and IT supply systems
100% regenerative feedback capability
Internal/external air cooling
Short-circuit/ground-fault-proof during the precharge phase
Integrated DC link and electronics current busbar connection
LEDs for indicating statuses and for diagnostic purposes
Characteristics of the Active Line Modules
Regulated DC link voltage
Regenerative feedback capability
Sinusoidal line currents
Electronic type plate
DRIVE-CLiQ interface for communication with the Control Unit and/or other components
in the drive line-up.
Integration in system diagnostics
Characteristics of the Smart Line Modules
Unregulated DC link voltage
Regenerative feedback capability
Square-wave line currents
Frequency with which the DC link is precharged
The frequency with which the DC link is precharged via the Line Module is determined using
the following formula:
1RRISUHFKDUJHV
ZLWKLQPLQV
0D[SHUPLVVLEOH'&OLQNFDSDFLW\
RI/LQH0RGXOHLQ¦)
ː'&OLQNFDSDFLW\RIFRQILJXUHGGULYH
OLQHXSLQ¦)
The maximum permissible DC link capacitance is specified in the technical specifications for
the Line Modules.
