Siemens SINAMICS Series Equipment Manual

Preface
Equipment Manuel for Booksize Power Modules
Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
vii
Caution
As part of routine tests, SINAMICS equipment with three-phase motors will undergo a
voltage test in accordance with EN 50178. Before the voltage test is performed on the
electrical equipment of industrial machines to EN 60204-1, Section 19.4, all connectors of
SINAMICS equipment must be disconnected/unplugged to prevent the equipment from
being damaged.
Motors must be connected in accordance with the circuit diagram provided. They must not
be connected directly to the three-phase supply because this will damage them.
Note
When operated in dry operating areas, SINAMICS equipment with three-phase motors
conforms to low-voltage Directive 73/23/EEC.
SINAMICS equipment with three-phase motors conforms to EMC Directive 89/336/EEC in
the configurations specified in the associated EC Certificate of Conformity.
Caution
Operating the equipment in the immediate vicinity (< 1.5 m) of mobile telephones with a
transmitter power of > 1 W may lead to incorrect operation.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
