Compact Scan Module (CSM) Technical Specifications
42
Software Restart Procedure
This method, which closes and restarts the ShopStream Diagnostic Suite software,
takes about two minutes to complete.
z To restart the ShopStream Diagnostic Suite:
1. Navigate to the Home Screen on the diagnostic tool.
2. Select Exit to close the ShopStream Diagnostic Suite.
3. Wait for the CSM Communication LED to stop flashing.
4. Select the ShopStream Diagnostic Suite icon on the desktop.
The ShopStream Diagnostic Suite should open with connectivity restored.
Windows Reboot Procedure
This method, which completely shuts down the diagnostic tool, takes several
minutes to complete.
z To reboot the diagnostic tool:
1. Disconnect the CSM from the vehicle.
2. Navigate to the Home Screen on the diagnostic tool.
3. Select Exit to close the ShopStream Diagnostic Suite.
4. Select Start in the lower-left corner of the screen to open the menu.
5. Select Turn Off Computer from the menu.
6. Select Turn Off when the Confirmation window opens.
7. Wait for the tool to completely turn off, then press the Power button to restart
the diagnostic tool.
8. Connect the CSM to the vehicle once the ShopStream Diagnostic Suite opens.
4.9 Technical Specifications
Item Description / Specification
Communications Wireless Bluetooth
®
2.1 Technology
Operating Range Approx. 50 feet (15.24 m)
USB Power 5V @ 500mA
DC Operating Power 8V to 32V, Maximum 10 Watts
Width 1.85 in. (47 mm)
Height 0.92 in. (23.4 mm)
Depth 4 in. (101.6 mm)
Weight 0.22 lb (100 g)
Operating Temperature
Range (ambient)
At 0 to 90% relative humidity (non-condensing)
32 to 113°F (0 to 45°C)
Storage Temperature
(ambient)
At 0 to 70% relative humidity (non-condensing)
–4 to 140°F (–20 to 60°C)
Operating Altitude Maximum 2000 m
Environmental Conditions
This product is intended for indoor use only
This product is rated for Pollution Degree 2 (normal
conditions)
