Intelligent Diagnostics Smart Data
79
Figure 6-10 TSB example
6.7 Smart Data
Smart Data filters out all non-relevant PIDs and shows you a custom list of PIDs
only related to the selected code. In addition, specific PIDs in the list are prearmed
using known-good upper and lower trigger values.
Smart Data works best when the vehicle is idling at operating
temperature with no load present. Always refer to OEM service
information for specific PID range limit information.
Selecting the Smart Data card (Figure 6-11) opens the Smart Data main menu
(Figure 6-12), which includes additional data list options (bottom of screen).
Figure 6-11
Selecting the Smart Data List (Figure 6-12) opens the custom code-specific PID list
(Figure 6-13).
Figure 6-12
Figure 6-13 Typical Smart Data PID list
