Sony XVS Series

218
a) When a minus value is specified, the picture is extended in the
vertical direction. When a plus value is specified, the picture is
extended in the horizontal direction.
Rotating the wipe crop pattern (Rotation)
1 In the <Rotation> group of the Wipe Crop menu
(4116), select one of the following.
Angle: Incline the pattern at a fixed angle.
Speed: Rotate the pattern at a set speed.
2 Depending on the selection in step 1, set the following
parameters.
When [Angle] is selected
a) –1.00 is one rotation in the counterclockwise direction. +1.00 is one
rotation in the clockwise direction. 0.00 is no rotation.
When [Speed] is selected
a) –100.00 is four rotations per second in counterclockwise direction.
+100.00 is four rotations per second in clockwise direction. 0.00 is in
stationary state.
Applying modulation to the wipe crop
pattern (Modulation)
1 In the <Modulation> group of the Wipe Crop menu
(4116), select one of the following.
H: Modulate the pattern to apply waving in the
horizontal direction.
V: Modulate the pattern to apply waving in the vertical
direction.
2 Set the following parameters.
Replicating the wipe crop pattern (Multi)
1 In the Wipe Crop menu (4116), press [Multi], turning
it on.
2 Set the following parameters.
a) See page 138.
Modifying the wipe crop pattern edge
(Edge)
You can apply a border to the wipe crop pattern, or soften
the boundary.
1 In the <Edge> group of the Wipe Crop menu (4116),
select one of the following.
Border: Border
Soft: Soft edge
Soft Border: Soft border
2 Depending on the selection in step 1, set the following
parameters.
When [Border] is selected
When [Soft] is selected
When [Soft Border] is selected
Setting the signal or color to be inserted in
the wipe crop border
When a border or soft border is applied to a wipe crop, you
can set the signal or color to be inserted in the border.
1 In the <Border Fill> group of the Wipe Crop menu
(4116), select one of the following.
Flat Color: Single color
Mix Color: Mix color signal set in the DME >Edge
>Color Mix menu (4117) (see page 219)
No. Parameter Adjustment
1 Aspect Aspect ratio
a)
No. Parameter Adjustment
1 Angle Rotation angle of pattern
a)
No. Parameter Adjustment
1 Speed Rotation speed of pattern
a)
No. Parameter Adjustment
1 Amplitude Amplitude of modulation
2 Frequency Frequency of modulation
3 Speed Speed of ripples
No. Parameter Adjustment
1 H Multi Number of repetitions of pattern
horizontally
2 V Multi Number of repetitions of pattern
vertically
3 Invert Type Pattern layout
a)
No. Parameter Adjustment
1 Width Border width
No. Parameter Adjustment
1 Soft Edge softness
No. Parameter Adjustment
1 Width Border width
2 Inner Soft Degree of softness inside the
border
3 Outer Soft Degree of softness outside the
border
