Chapter
19
400
Switcher Setup
Settings Relating to
Switcher Configuration
Adjusting the Reference Phase
This adjusts the switcher internal reference phase.
In the Engineering Setup >Switcher >Config menu (7331),
set the following parameter.
Specifying the Video Switching
Timing
1
In the Engineering Setup >Switcher >Config menu
(7331), press [Switching Timing].
The Switching Timing menu (7331.8) appears.
2
Select one of the following.
Any: Not specified
Field 1: Field 1
Field 2: Field 2
When the signal format is 3840×2160P, 1080P, 1080PsF,
or 720P, the switching timing cannot be specified.
Setting the Operation Mode
This sets the output signal configuration for each bank.
1
Open the Engineering Setup >Switcher >Config menu
(7331).
2
In the status area, select the target switcher bank to set.
3
In the <M/E Config> group, select the operation mode.
Standard: Standard mode
Multi Program: Multi-program mode
DSK: DSK mode (PGM/PST only)
About the operation mode
• Standard mode: Fix the output signal configuration for
the maximum of four outputs (Out1 to 4) of the M/E and
PGM/PST banks as follows.
- Out1: Program output
- Out2: Preview output
- Out3: Clean output
- Out4: Key preview output
1)
• Multi-program mode: Increase the number of M/E or
PGM/PST program systems, and assign one of the
following to up to six outputs (Out1 to 6) (M/E Output
Assign).
- Program outputs 1 to 4
- Preview output
- Key preview outputs
1)
1 and 2
- Clean output
Further, you can change the combination of signals from
which the program output is configured (PGM Config).
• DSK mode: Treats PGM/PSTs as DSKs by assigning
one of the Out1 to Out6 program outputs of M/E-1 to M/
E-5 to the background. You can change the signals that
make up the program output and key preview output
1)
using PGM Config and K-PVW Config.
1) For the key preview output, you can select either video mode (background
and key) or key mode (key only), and select the background and key (K-
PVW Config).
• When Multi-program mode is selected, two or more
transition type selection buttons may be lit on the
transition control block. Also, more than one
<Transition Type> group button may be selected in the
Misc >Transition menu of each M/E and PGM/PST
bank.
• In 4K format, only standard mode and DSK mode can be
configured.
However, the output in DSK mode has the following
configuration.
- Out1: Program output 1
No. Parameter Adjustment
3 Phase Switcher internal reference phase
Note
Notes
