430
Tally Generation Settings
Specify the destination to be the reference for tally
generation, and configure the settings.
The settings used are common to both parallel and serial
tallies.
Configuring Tally Generation
1
In the Engineering Setup >Router/Tally >Tally Enable
menu (7364), press [New].
The New menu (7364.1) appears.
2
Set the following parameters.
a) 1: R1, 2: G1, 3: R2, 4: G2, 5: R3, 6: G3, 7: R4, 8: G4, 9: R5, 10: G5,
11: R6, 12: G6, 13: R7, 14: G7, 15: R8, 16: G8 (R stands for Red
Tally, and G for Green Tally)
3
In the <Tally Enable> group, specify the tally
generation mode.
Enable: Always generate a tally.
Disable: Never generate a tally.
Tally Input: Generate a tally from the tally input state.
4
When [Tally Input] is selected in step 3, select one of
the following in the <Tally Input> group.
DCU1: Generate tally with reference to signal that is
input on the SIU1 (DCU function) port.
DCU2: Generate tally with reference to signal that is
input on the SIU2 (DCU function) port.
Select the tally input port number using the following
parameter.
5
Press [Execute].
Modifying Tally Generation
1
In the Engineering Setup >Router/Tally >Tally Enable
menu (7364), press [Modify].
The Modify menu (7364.2) appears.
2
Refer to steps 2 to 4 in “Configuring Tally
Generation” (page 430) and modify the parameters.
3
Press [Execute].
Deleting Tally Generation
1
In the Engineering Setup >Router/Tally >Tally Enable
menu (7364), select the tally generation.
2
Press [Delete].
No. Parameter Adjustment
1 Destination
Address
Destination address
2 Destination
Level
Destination level
3 Tally Type Tally type
a)
No. Parameter Adjustment
5 Input Port Tally input port number
To Next Page
