Wiring Settings
When configuring a system in which the switcher inputs
and outputs are connected to a router, the connection
configuration (referred to as “wiring”) must be set S-Bus
space (inputting physical connection information).
The settings used are common to both parallel and serial
tallies.
Configuring Wiring
1
In the Engineering Setup >Router/Tally >Wiring
menu (7363), press [New].
The New menu (7363.1) appears.
2
Set the destination.
When configuring more than one wiring setting, you
can specify the destination start and end addresses.
3
Set the source.
4
Press [Execute].
Modifying Wiring Settings
1
In the Engineering Setup >Router/Tally >Wiring
menu (7363), press [Modify].
The Modify menu (7363.2) appears.
2
Set the destination and source.
It is not possible to modify the settings for multiple
destinations at the same time.
3
Press [Execute].
Deleting Wiring Settings
1
In the Engineering Setup >Router/Tally >Wiring
menu (7363), select the wiring.
2
Press [Delete].
Sorting Wiring Settings
In the Engineering Setup >Router/Tally >Wiring menu
(7363), press [Sort].
The sorting of wiring settings is executed in the following
sequence.
Destination level order (ascending) t Destination
address order (ascending) t Source level order
(ascending)
No. Parameter Adjustment
1 Destination
(From)
Destination start address
2 Destination
(To)
Destination end address
3 Destination
(Level)
Destination level
No. Parameter Adjustment
4Source
(From)
Source start address
5Source
(Level)
Source level
No. Parameter Adjustment
1 Destination
(Address)
Destination address
2 Destination
(Level)
Destination level
3 Source
(Address)
Source address
4 Source
(Level)
Source level
