415
Settings Relating to
Function Links
Setting a Cross-Point Button Link
This configures the bus link function that links together
two buses within the switcher.
1
In the Engineering Setup >Switcher >Link menu
(7336), press [Internal Bus Link].
The Internal Bus Link menu (7336.1) appears.
2
Select the target link number to set.
3
Press [Link Bus Select].
The Link Bus Select menu (7336.2) appears.
4
In the <Bus Select> group, select [Master Bus] (link
source bus).
5
Select the bus for the link source, and press [Bus Set].
M/E-1 to 5 Trans PGM and P/P Trans PGM can be set
only when [Master Bus] is selected.
When one of M/E-1 to M/E-5 Trans PGM or P/P Trans
PGM is selected for [Master Bus], the link setting
becomes effective as soon as you start moving the
fader lever.
6
In the <Bus Select> group, select [Linked Bus] (link
destination bus).
7
Select the bus for the link destination, and press [Bus
Set].
AUX1 to 48 as Key can be set only when [Linked Bus]
is selected.
8
Select the link table, and press [Link Table Set].
To release the link
In the Engineering Setup >Switcher >Link >Internal Bus
Link menu (7336.1), select a link and press [Clear].
Setting a Link Table
1
In the Engineering Setup >Switcher >Link >Internal
Bus Link menu (7336.1), press [Link Table Select].
The Link Table Select menu (7336.3) appears.
2
Select the link source and link destination signals.
3
Press [Link Src Set].
To initialize the set source address
Press [Init Link Table], check the message, then press
[Yes].
To change the link number and link table number
Select the link number and link table number, and press
[Link Table Set].
Setting a Link Between M/E Banks
The operations which can be linked are as follows.
• Transition execution (auto transition, cut, and fader lever
operation)
• Next transition selection
• Transition type selection
1
In the Engineering Setup >Switcher >Link menu
(7336), press [M/E Link].
The M/E Link menu (7336.6) appears.
The status area displays a link list showing link source
banks and link destination banks (M/E and PGM/
PST), and a selection list.
2
Select the target link number to set.
3
In the <M/E Select> group, select [Master M/E] (link
source).
4
Select the M/E or PGM/PST link source, then press
[M/E Set].
5
In the <M/E Select> group, select [Linked M/E] (link
destination).
Note
No. Parameter Adjustment
3Link Table
No
Link table selection
No. Parameter Adjustment
4 Main No Video/key signal for link source
5 No Video/key signal for link destination
No. Parameter Adjustment
1 Link No Target link number to set
3Link Table
No
Link table number
To Next Page
