235
Applying the Circle effect
In the Non Linear >Circle menu (4141.17), set the
following parameter.
To make the axis of modulation vertical
Press [Mod V], turning it on.
The axis of modulation when modulating to a circle
becomes vertical.
Panorama Settings
You can set the horizontal and vertical curvature, and the
curve center position.
Applying the Panorama effect
In the Non Linear >Panorama menu (4141.18), set the
following parameters.
Page Turn Settings
There are four modes: H&V, H, V, and Off. You can select
the turn position, the radius of the turned portion, the
amount and angle of turning, and the input video for the
front and back pages.
Applying the Page Turn effect
1
In the <Split Mode> group of the Non Linear >Page
Turn menu (4141.19), select the partition method.
H&V: The image turns as it is split from the center
into 4 parts: left, right, upper, lower.
H: The image turns as it is split from the center into 2
parts: left, right.
V: The image turns as it is split from the center into 2
parts: upper, lower.
When nothing is selected (Off): There are no splits
and the image turns from the edge.
2
Set the following parameters.
To set the input signal for the back page
1
In the <Back Video> group, select the signal input for
the back page.
Self: Use the same signal as the front page.
Flat: Use a single color.
Hue Rotation: Gradually vary the hue.
2nd Ch: Use the 2nd channel video signal.
To select 2nd Ch, you must select the DME for the
second channel beforehand.
For details, see “DME Effects for Keys” (page 113)
and “DME Effects for Keys” (page 119).
2
Set the following parameters, according to the selected
input signal.
When [Flat] is selected
When [Hue Rotation] is selected
If Page Turn is used on one channel when the signal format
is 1080P (for example, when the input is a title), parts of
the back page other than the title appear as black.
Roll Settings
There are four modes: H&V, H, V, and Off. You can select
the turn position, the radius of the turned portion, the
amount and angle of turning, and the input video for the
front and back pages.
Applying the Roll effect
Open the Non Linear >Roll menu (4141.20).
The items and parameters displayed in the Roll menu are
the same as for the Page Turn menu (see page 235).
No. Parameter Adjustment
1 Radius Size of circle
No. Parameter Adjustment
1 Curve H Horizontal curvature
2 Curve V Vertical curvature
3 Position H Horizontal curve center position
4 Position V Vertical curve center position
No. Parameter Adjustment
1 Radius Radius of turn part
2 Offset Amount of turn
3 Angle Angle of turn
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3 Speed Speed at which the hue changes
Note
No. Parameter Adjustment
