Sony XVS Series User Manual

91
The A bus and B bus output for a NAM transition type is
an image created using non-additive mixing.
The transition indicator displays the progress of the
background A bus.
Transition Preview
With the preview output of the M/E bank and PGM/PST
bank, you can check the effect of a transition in advance.
To perform a transition preview, the [TRANS PVW]
button must be assigned to a button in the transition control
block beforehand in the Setup menu (see page 376).
• It is not possible to carry out a transition preview in the
following cases.
- Transitions in progress
- Multi-program mode
-DSK mode
- Bus fixed mode
• Transition preview operations are not supported using
the transition control block (simple type).
There are three modes for a transition preview.
Hold mode: Transition preview mode is enabled only
while the [TRANS PVW] button is pressed.
Lock mode: Pressing the [TRANS PVW] button switches
between transition preview mode and normal mode
each time the button is pressed.
One-time mode: Pressing the [TRANS PVW] button
switches to transition preview mode, and the mode
returns to normal mode when the transition finishes.
Set the transition preview mode in the following
combinations in the Setup menu.
For details, see “Setting the Button and Fader Lever
Operation Mode” (page 393) and “Setting the transition
preview mode” (page 412).
Carrying out a transition preview
1 Press the [TRANS PVW] button in the transition
control block.
The [TRANS PVW] button is lit green, and the
switcher enters transition preview mode. At this point,
the preview output is the same as the program output
before the [TRANS PVW] button was pressed.
Fader lever position Output
Right lever
(A bus)
Left lever
(B bus)
A bus B bus
Top Top 100% 0%
Top Bottom 100% 100%
Bottom Top 0% 0%
Bottom Bottom 0% 100%
Center Center 50% 50%
Note
Notes
Transition
preview
mode
<Transition Preview>
group in the
Engineering Setup
>Switcher
>Transition menu
(7334)
<Trans Pvw> group
in the Engineering
Setup >Panel
>Operation >Custom
Button/Fader menu
(7326.4)
Lock Normal Lock
Hold Normal Hold
One-time One Time –

Sony XVS Series Specifications

General

Category	Video Switcher
Outputs	Up to 48 outputs (depending on model)
Frame Memory	Varies by model and configuration.
Multi-viewer	Yes (depending on model)
Control Interface	Ethernet
Power Supply	Redundant power supply options available.
Keyers per M/E	Up to 8 keyers per M/E (depending on model)
