Rounding art edge corners
In the Art Edge menu (4114), press [Round Corner],
turning it on.
The art edge corners on the inner and outer sides are
rounded.
This function is only enabled when [Soft] is selected.
Flex Shadow Settings
• When the signal format is 1080P, the following flex
shadow functions cannot be used.
- [External] in the <Flex Shadow Source> group
- [Ext Video] in the <Flex Shadow Fill> group
• [Mix Color] or [Ext Video] can only be applied to one of
the background (see page 250), flex shadow, trail (see
page 240), and wind (see page 243) effects. If [Mix
Color] or [Ext Video] is selected for one of these effects,
the [Mix Color] or [Ext Video] for the other effects is
disabled, and [Flat Color] is selected in its place.
• When executing a 4-channel combination, the [Mix
Color] and [Ext Video] for flex shadow and background
effects cannot be selected.
Applying a flex shadow effect
1 Open the DME >Edge >Flex Shadow menu (4115).
2 Press [Flex Shadow], turning it on.
The flex shadow function cannot be enabled when the
following functions are enabled.
• All nonlinear effects
• Brick and shadow global effects
3 Set the following parameters.
a) The Soft parameter is valid only when [Internal] is selected in the
<Flex Shadow Source> group.
4 In the <Flex Shadow Source> group, select the signal
to use for the flex shadow.
External: Generate using an input key signal.
Internal: Generate using a full-size key signal.
5 In the <Flex Shadow Fill> group, select the signal for
the flex shadow portion.
Flat Color: Single color
Mix Color: Mix color signal set in the DME >Edge
>Color Mix menu (4117) (see page 219)
Ext Video: External video signal input from Ext In
6 When [Flat Color] is selected in step 5, set the
following parameters.
Adjusting the size of the flex shadow
1 In the Flex Shadow menu (4115), press [Size].
2 Set the following parameters.
a) The Soft parameter is valid only when [Internal] is selected in the
<Flex Shadow Source> group.
Setting the center point of the flex shadow
1 In the Flex Shadow menu (4115), press [Axis Loc].
2 Set the following parameters.
Note
Notes
Note
No. Parameter Adjustment
1 H Move shadow horizontally
2 V Move shadow vertically
3 Size All Enlarge or shrink horizontally and
vertically
4Soft
a)
Softness of shadow
5 Density Density of shadow
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
No. Parameter Adjustment
1 Size H Enlarge or shrink horizontally
2 Size V Enlarge or shrink vertically
3 Size All Enlarge or shrink horizontally and
vertically
4 Soft
a)
Softness of shadow
5 Density Density of shadow
No. Parameter Adjustment
1 Axis Loc H Move the shadow center axis
horizontally
2 Axis Loc V Move the shadow center axis
vertically
