Sony XVS Series - Rings Settings; Broken Glass Settings; Flying Bar Settings

231
Other settings
You can configure [Lock], [Form], [Random], and [Range
Envelope].
The operation is the same as [Lock], [Form], [Random],
and [Range Envelope] in the Wave menu (4141.1).
For details, see “Wave Settings” (page 226).
Rings Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
amount of movement, the width of the partitions, the
degree of randomness in partition width, the center point,
the starting angle, and other parameters.
To apply the Rings effect
1 Open the Non Linear >Rings menu (4141.7).
2 To make transition settings, press [Transition] and set
the following parameters.
3 To set the partition method, press [Partition] and set
the following parameters.
4 To set the ring center position, press [Position] and set
the following parameters.
5 To partition into pixels, press [Pixel], turning it on,
and set the following parameters.
Broken Glass Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
amount of movement, the width of the partitions, the
degree of randomness in partition width, the center point,
the starting angle, and other parameters.
You can also fix the direction in which shards scatter.
To apply the Broken Glass effect
Open the Non Linear >Broken Glass menu (4141.8).
The items and parameters displayed in the Broken Glass
menu, excluding [Direction], are the same as for the Rings
menu (see page 231).
To fix the direction in which shards scatter
Press [Direction], turning it on.
Flying Bar Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
direction of movement, the width of the partitions, the
degree of randomness in partition width, the partition
angle, and other parameters.
To apply the Flying Bar effect
1 Open the Non Linear >Flying Bars menu (4141.9).
2 To make transition settings, press [Transition] and set
the following parameters.
3 To set the partition method, press [Partition] and set
the following parameters.
No. Parameter Adjustment
1 Transition Degree of transition
2 Random Degree of randomness in distance
moved by each block
3 Spiral Amount of movement toward
circumference accompanying
transition
No. Parameter Adjustment
1 Width Width of partition
2 Random Degree of randomness in partition
width
3 Angle Starting angle of effect
No. Parameter Adjustment
1 H Center point in horizontal direction
2 V Center point in vertical direction
No. Parameter Adjustment
1 Density Degree to which image disappears
around periphery
2 Random Degree of jaggedness at block
edges
No. Parameter Adjustment
1 Transition Degree of transition
2 Random Degree of randomness in distance
moved by each block
3 Angle Direction of movement
No. Parameter Adjustment
1 Width Width of partition
2 Random Degree of randomness in partition
width
3 Angle Partition angle
No. Parameter Adjustment
