262
File related functions
As effect data, you can save and recall, using the File
menu.
Control of P-Bus Devices
In this system, you can control P-Bus (Peripheral Bus II
protocol) external devices through the 9-pin serial port of
an SIU.
P-Bus device control modes
There are two modes of P-Bus device control, as follows.
Trigger: Operating a previously specified button outputs
the command for an action assigned to that button.
Timeline: Carrying out a keyframe effect under the
control of the center control panel controls external
devices.
In the Setup menu, select which of Trigger mode and
Timeline mode to use.
You can set the following actions (set what action
command is output to which device) in both modes.
•Store
• Recall
•Trigger
Creating and Editing the P-Bus
Timeline
At a keyframe point on the P-Bus timeline, you can set an
action. At any single keyframe point you can set actions
for a maximum of 24 devices.
For details about keyframe creation, see “Creating and
Editing Keyframes” (page 288).
For the action setting (or P-Bus timeline editing), use the
Device menu.
You can save the data set in the Device menu in keyframe
effect registers. Recalling the register starts execution of
the keyframe effect, and when this reaches the keyframe
point at which actions are set, action commands are output
to external devices through the 9-pin serial port assigned to
P-Bus.
To use the P-Bus timeline, the P-Bus control mode must be
set to [Timeline] in the Setup menu (see page 391).
Setting an action
1
Open the Device >P-Bus Timeline >P-Bus Timeline
menu (5321).
In the status area, two lists appear. The left list displays
combinations of devices and actions. The content of
Note
