Power Supply and Connector Section

XVS-8000 Multi Format Switcher

Front view

POWER A, B, C, D switch and status indicators

Turn the POWER switch on/off to power the unit on/off.

The unit is turned on when the POWER switch is in the “?”

position, and turned off when in the “1” position.

The status indicators light green when the units are

powered on. The status indicators light orange when units

are switched off.

POWER A, B, C, D switch and status indicators
