43
c Memory recall buttons
This section displays the functions assigned to the buttons
for the selected operation mode.
When two utility/shotbox control blocks are used, the
memory recall button settings for the same mode selection
buttons are common to both blocks.
Function recall mode
This displays the function specified in the selected bank.
You can change the assignment of the following functions
to the memory recall buttons in the Setup menu.
• Menu shortcut
• Utility command
• Macro register
• Shotbox register
For details, see “Assigning a Function to a Memory Recall
Button in the Utility/Shotbox Control Block” (page 387).
Transition rate display mode
This mode displays the transition rate set in the image
creation banks (M/E-1 to M/E-5, PGM/PST) and keys
(KEY1 to KEY8).
Pressing a button displaying a transition rate enables you
to enter a transition rate using the numeric keypad control
block.
You can change the assignment of transition rate display
buttons in the Setup menu.
For details, see “Setting the transition rate target to
display on memory recall buttons” (page 389).
Keyframe/macro editing mode
This mode displays buttons used for editing keyframe
effects and macros.
You can edit effects and macro registers recalled using the
numeric keypad control block.
AUX Bus Control Block
You use the AUX bus control block for bus signal
selection and router operations.
You switch between AUX bus operation mode and router
operation mode using the [RTR MODE] button on the
cross-point pad.
To use as an AUX bus control block, the control panel
target row must be set to an AUX row in the Engineering
Setup >Panel >Config menu (7321).
For details, see “Setting the Configuration for Each
Bank” (page 372).
REWIND Returns to the first keyframe of the
effect.
RUN • Executes an effect from the first
keyframe.
• When paused, execution stops at
that point, and then resumes
when you press the [RUN]
button.
Note
Button name Description
Note
To Next Page
