Sony XVS Series - Blind Settings; Split Settings; Split Slide Settings

232
Blind Settings
You can set the number of rotations by blocks, the
perspective, the width and position of blocks, the direction,
the center position, and other parameters. There are two
modes: Bar and Wedge.
To apply the Blind effect
1 In the <Mode> group of the Non Linear >Blind menu
(4141.10), select the mode.
Bar: Bar mode
Wedge: Wedge mode
2 To make transition settings, press [Transition] and set
the following parameters.
3 To set the partition method, press [Partition] and set
the following parameters.
When [Bar] is selected in the <Mode> group
When [Wedge] is selected in the <Mode> group
To set the wedge center position
When [Wedge] is selected in the <Mode> group, you can
set the wedge center position.
1 Press [Position].
2 Set the following parameters.
Split Settings
You can set the degree to which the image is split, the split
positions, and other parameters.
Applying the Split effect
1 In the <Mode> group of the Non Linear >Split menu
(4141.11), select the partition method.
Single: Leave gaps between splits as-is.
Double: Fill gaps between splits with the same image.
2 Set the following parameters.
To set the split position
1 Press [Position].
2 Set the following parameters.
Split Slide Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
degree of sliding, block width, block angle, and other
parameters.
Applying the Split Slide effect
In the Non Linear >Split Slide menu (4141.12), set the
following parameters.
No. Parameter Adjustment
1 Rotation Number of rotations of the blocks
2 Perspective Degree of randomness in distance
moved by each block
No. Parameter Adjustment
1 Width Width of partition
2 Offset Degree of randomness in partition
width
3 Angle Starting angle of effect
No. Parameter Adjustment
4 No Width of blocks
5 Phase Partition position
No. Parameter Adjustment
1 H Center point in horizontal direction
2 V Center point in vertical direction
Parameter group [1/2]
No. Parameter Adjustment
1 Transition
H
Degree of left and right separation
2 Transition
V
Degree of top and bottom
separation
Parameter group [2/2]
No. Parameter Adjustment
1 Top Offset of top edge
2 Left Offset of left edge
3 Right Offset of right edge
4 Bottom Offset of bottom edge
No. Parameter Adjustment
1 H Degree of left and right separation
2 V Degree of top and bottom
separation
