Sony XVS Series - Lens Settings; Circle Settings

234
Applying the Kaleidoscope effect
In the Non Linear >Kaleidoscope menu (4141.15), set the
following parameters.
To reflect the kaleidoscope image as if in a mirror
To reflect in the horizontal direction, press [Mirror H],
turning it on.
To reflect in the vertical direction, press [Mirror V],
turning it on.
To set the reflection position
1 Press [Position].
2 Set the following parameters.
To cyclically repeat part of the original and its
reflection
Press [Cyclic], turning it on.
Lens Settings
You can set the shape and aspect ratio of the lens, the
angle, the magnification ratio, the curvature, the size, the
center position, and other parameters.
You can also choose to display only the portion of the
image that is seen through the lens.
Applying the Lens effect
1 In the <Mode> group of the Non Linear >Lens menu
(4141.16), select the lens shape.
Circle: Circular shape
Rectangle: Rectangular shape
Star: Star shape
Heart: Heart shape
Bar: Bar shape
Cross: Cross shape
2 Set the following parameters, according to the selected
lens shape.
When [Circle], [Rectangle], [Star], or [Heart] is
selected
When [Bar] is selected
When [Cross] is selected
To make only the lens part visible
Press [Lens Only], turning it on.
The parts of the image outside the lens are removed.
To set the lens center position
1 Press [Position].
2 Set the following parameters.
Circle Settings
You can set the size of the circle. You can also make the
axis of modulation vertical.
No. Parameter Adjustment
1 Number Number of blocks
2 Phase Angle of partition reference point
3 Offset H Horizontal offset
4 Offset V Vertical offset
No. Parameter Adjustment
1 H Horizontal reflection position
2 V Vertical reflection position
No. Parameter Adjustment
1 Magnify H Magnification ratio
2 Curve H Curvature
3 Size H Size
4 Angle Slant angle
5 Aspect Aspect ratio
No. Parameter Adjustment
1 Magnify H Magnification ratio
2 Curve H Curvature
3 Size H Size
4 Angle Slant angle
Parameter group [1/2]
No. Parameter Adjustment
1 Magnify H Horizontal magnification ratio
2 Curve H Horizontal curvature
3 Size H Horizontal size
Parameter group [2/2]
No. Parameter Adjustment
1 Magnify V Vertical magnification ratio
2 Curve V Vertical curvature
3Size V Vertical size
No. Parameter Adjustment
1 H Lens center position in horizontal
direction
2 V Lens center position in vertical
direction
